Vanguard Three-Phase UPS 10-40 kVA Model
Unstoppable Power When You Need It Most
Our NXT Power Vanguard 10-40kVA Three-Phase UPS is a true online double conversion UPS. It is specifically designed to handle the power needs of mission-critical loads. Providing maximized uptime with clean and uninterrupted power for your mission-critical applications with industry-leading efficiency, durability, and performance.
Vanguard Three-Phase UPS 10-40 kVA Model North American Specs
| Model # | Input Voltage AC~ | Output Voltage AC~ | Maximum Load Rating (AMPS) | Maximum Power (VA) | Frequency (HZ) | Case Size (IN) | Ship Weight (LBS) |
|---|---|---|---|---|---|---|---|
| NPU 10.0 | 208V 3 Phase | 200/208/220 | 28 | 10,000 | 50/60 | 10.23 x 33.46 x 35.00 | 76 w/o Batteries |
| NPU 15.0 | 208V 3 Phase | 200/208/220 | 41 | 15,000 | 50/60 | 10.23 x 33.46 x 35.00 | 105 w/o Batteries |
| NPU 20.0 | 208V 3 Phase | 200/208/220 | 55 | 20,000 | 50/60 | 16.14 x 33.46 x 38.40 | 115 w/o Batteries |
| NPU 30.0 | 208V 3 Phase | 200/208/220 | 83 | 30,000 | 50/60 | 16.14 x 33.46 x 38.40 | 155 w/o Batteries |
| NPU 40.0 | 208V 3 Phase | 200/208/220 | 111 | 40,000 | 50/60 | 16.14 x 33.46 x 38.40 | 160 w/o Batteries |
Balanced Efficient Industrial Power
The Vanguard Three-Phase UPS is engineered and built to power larger critical systems having high inrush current and high crest factor. Low input THDi and high input power factor characteristics result in reduced installation costs and high-efficiency design means very low operating costs. Engineered with state-of-the-art manufacturing using only high-quality components results in a highly reliable and durable product.
Our three-phase UPS systems are also engineered to maximize your business' uptime, ensuring that your critical systems stay operational even in the event of a power outage. With advanced features like real-time monitoring and automatic voltage regulation, you can trust that your business will stay online when you need it most.
- Advanced Operation Interface - LCD Touchscreen
- High Input Power Factor >0.99 & Output Power Factor 1.0
- 3 Level IGBT Technology
- Built-in High Current Battery Charger
- Flexible Battery Configuration
- UL Listed and CE marked
- Available DC Start Function
- Strong Over Load Capacity
- Battery cabinet sold separately for extended runtime
- OSHPD/HCAi Listed*
- Includes NXT Power 2-year warranty
Product Documentation
- Vanguard 3 Phase 10-40KVA UPS Fact Sheet
- Vanguard 3 Phase 10-40KVA UPS User Manual (PDF)
- Vanguard 3 Phase 10/15/20KVA UPS Battery Cabinet Manual (PDF)
- Vanguard Three-Phase 30/40KVA Battery Cabinet (PDF)
- Vanguard Three Phase 10-40KVA UPS SNMP Manual
- Warranty (PDF)
- Quality Policy Certificate (PDF)
- CB Test Certificate (PDF)
- Vanguard 3 Phase 10-40KVA UPS Site Planning Guide (PDF)
- Vanguard 3 Phase 10-40KVA UPS MBS Data Sheet (PDF)
Product Support
Industries & Applications
The NXT Power Vanguard 10-40kVA Three-Phase UPS systems are specifically designed to handle the power needs of mission-critical loads the perfect choice for applications such as data centers, large networks, and light industrial sites where even a momentary power outage can cause significant disruption and damage.
